1-Phase Power Network Digital Panel Meter, N30P

Description PRODUCT DESCRIPTION N30P meter is destined to measure: a.c. voltage, a.c. current, active, reactive and apparent power, cos φ, tg φ, φ, frequency, active, reactive and apparent energy, 15 min. active power, 10 min. voltage, 10 sec. frequency in single-phase power network. Features: Input: current: 0…1 or 0…5A voltage: 0…100V or 0…400V Output: relay (4), analog (1), energy pulse (1), digital RS485/MODBUS (1) 3-colour display – red, green and orange programmable in three intervals of the measured value 14mm digit hight highlighted measuring units 4 alarm outputs with signalling by LED diodes, operating in 6 different modes, Conversion of any measured value into a 0/4…20mA or 0…10V analog signal, Storage of minimal and maximal values for all measured quantities, Meter programming from the keyboard or through the RS485 interface by means of free delivered LPConfig software. Parameters which can be reprogrammed are as follows: display colour, individually in three intervals, thresholds of displayed overflows, display precision of the result (decimal point), highlight of the unit, averaging time of the measurement, recounting of indications (individual characteristic). Supply: 85…253 V AC/DC or 20…40 V AC/DC Protection level from frontal side: IP65, External simension: 96 x 48 x 64mm. SPECIFICATIONS Inputs Input kind Measuring range Min…max signal value Ratio values Voltage input 0…100 V or 0…400 V 0.05…1.2 Un 0.1…4000.0 Current input 0…1 A or 0…5 A 0.005…1.2 In 1…10000 Measuring ranges Measured value Indication range Measuring range Basic error Current 1 A/5 A 0.000…60 kA 0.02…6 A a.c. ± 0.2% Voltage 100 V/400 V 0.0…192 MV 1…480 V a.c. ± 0.2% Frequency 45.00…100.00 Hz 45.00…66.00…100.00 Hz ± 0.2% Active power -19999…99999 MW -2.88 kW…1.40 W…2.88 kW ± 0.5% Reactive power -19999…99999 Mvar -2.88 kvar…1.40 var…2.88 kvar ± 0.5% Apparent power 0.00…99999 MVA 1.40 VA…2.88 kVA ± 0.5% Cofficient PF -1…1 -1…0…1 ± 0.5% Tangens φ -1.2…1.2 -1.2…0…1.2 ± 1% φ 0…359 0…359 ± 1% Active energy 0…9 999 999.9 kWh 0…9 999 999.9 kWh ± 0.5% Reactive energy 0…9 999 999.9 kVarh 0…9 999 999.9 kVarh ± 0.5% Apparent energy 0…9 999 999.9 kVA 0…9 999 999.9 kVA ± 0.5% Current time 0.00…23.59 0.00..23.59 1 sec/ 24 h Outputs Output kind Properties Remarks Relay output • 2 x relays, voltageless NO contacts, load-carrying capacity 250 V a.c./ 0.5 A a.c. • 2 x relays, voltageless CO contacts, load-carrying capacity 250 V a.c./ 0.5 A a.c. 2 x contacts optional Analog output • current programmable 0/4…20 mA, load resistance ≤ 500 Ω • voltage programmable 0…10 V, load resistance ≥ 500 Ω • resolution 0.01 % of the range optional resolution 0.01% of the range Energy pulse output • OC type, passive; supply: voltage 18…27 V, current 10…27 mA; A class acc. to EN 62053-31 • Output pulse constant: 5000 imp./kWh, independently of Ku and Ki settings   Digital interface Interface type Transmission protocol Modes Baud rates RS-485 MODBUS RTU 8N2, 8E1, 8O1, 8N1 4.8, 9.6, 19.2, 38.4 kbit/s External features Readout field 5 digit LED display , indication range -19999..99999 digit, height: 14 mm three-colour display (colour changes depending on displayed value): red, green, orange Weight < 0.2 kg   Dimensions 96 x 48 x 93 mm Panel cut out: 92 0,6 x 45 0,6 mm Protection level (acc. to EN 60529) from frontal side: IP65 from rear side: IP10 Rated operating conditions Supply voltage 85..253 V a.c./d.c. (40..400Hz) or 20..40 V a.c./d.c. (40..400Hz) Power consumption < 6 VA Temperature ambient: -25..23..55 °C storage: -33..70 °C Relative humidity 25..95% condensation inadmissible Working position any   External magnetic field 0…400 A/m   Short duration overload (5 s) voltage input: 2Un (max. 1000 V) current input: 10 In Safety and compatibility requirements Electromagnetic compatibility Noise immunity acc. to EN 61000-6-2 Noise emission acc. to EN 61000-6-4 Safety requirements   acc. to EN 61010-1  CONNECTION DIAGRAMS Fig. 1 Electrical connections of the N30P meter for direct measurements. Fig. 2 Electrical connections of the N30P meter for indirect measurements.
